Comprehensive Property Redevelopment: Extension & Additional Flats | Brent

Project Overview

* Location: Wembley, Brent

* Services Provided: Concept Design, Measured Survey, Planning Drawings, Internal Layout Reconfiguration & 3D Architectural Visualisation

* Scope of Work: Partial Single, Partial Double Storey Side Extension, Flat Conversion, Loft Conversion & Internal Reconfiguration

* Key Design Elements: Hip-to-gable roof design with rear dormer, multi-unit flat conversion, internal spatial optimization, side extension, and all associated works

This comprehensive property redevelopment project in the London Borough of Brent demonstrates a maximum-yield architectural design strategy, transforming a dwelling into multiple high-specification flats. The scheme integrates a partial single-story and partial two-storey side extension, a hip-to-gable roof conversion with a large rear dormer, and complete internal reconfiguration.

By delivering full architectural drawings and planning application support, this project highlights how tailored design maximizes space, satisfies strict local planning policy, and unlocks maximum development value.

Architectural Design & Planning Strategy

1. Partial Single & Two-Storey Side Extension

To maximize internal floor area without visually overpowering the street scene, the architectural drawings incorporate a stepped side extension design. The ground floor utilizes full depth to expand living areas, while the upper floor is set back to adhere to Brent planning guidelines regarding residential dominance and light protection for adjacent properties.

2. Hip-to-Gable & Rear Dormer Loft Conversion

The existing roof structure was overhauled using a hip-to-gable conversion, extending the ridge line sideways to create usable internal headroom. A large rear dormer was added to accommodate additional bedrooms and en-suite facilities, utilizing high-performance materials and rooflights to maximize natural light.

3. Flat Conversion & Internal Reconfiguration

The floor plan layout was redesigned to divide the property into self-contained, compliant residential units. The architectural plans carefully manage:

Means of Escape & Fire Safety: Dedicated protected corridors and compliant exit routes.

Acoustic Insulation: Designed in accordance with Approved Document E standards for party walls and floors.

Amenity Space & Refuse Storage: Designated areas for outdoor space, bike storage, and waste management required by Brent Council.
